Name: XL4016 DC 10A 300W Step Down Buck Converter
SKU: VE-135
Availability: InStock

XL4016 DC 10A 300W Step Down Buck Converter

Technical Specifications

Characteristic	Specification Parameters
Converter Circuit Core	XL4016E1 Non-Isolated Buck Switching Regulator
Input Supply Voltage (VIN)	7.0V to 40.0V DC (Input must be higher than target output)
Adjustable Output (VOUT)	1.2V to 35.0V DC (Continuously variable via CV trimmer)
Output Current Capacity	0.2A to 8A Continuous (Hits up to 10A Maximum with active fan cooling)
Maximum Output Power	Up to 300W Peak Performance Capacity
Fixed Switching Frequency	180 kHz / 300 kHz (Depending on exact board revision)
Output Voltage Ripple	~50 mV peak-to-peak frequency ripple
Chassis Dimensions	Approx. 65 mm × 47 mm × 24 mm

SKU: VE-135 Category: Converters

The XL4016 10A 300W DC-DC Step-Down Buck Converter Module is a high-power switching regulator board engineered to lower high DC input voltages down to a stable, lower DC output voltage. Driven by the monolithic XL4016E1 buck chip, this heavy-duty variant is equipped with a Dual-Trimpot Constant Current (CC) and Constant Voltage (CV) adjustment layout. Capable of outputting up to 300W of raw power, it is a premier solution across India for creating variable laboratory bench power supplies, driving high-wattage LED arrays, and charging custom lithium or lead-acid batteries.

✨ Key Features

Dual CC/CV Control Function: Populated with two independent multi-turn trimmer potentiometers to control both the output voltage ceiling and the maximum threshold current. [
Massive 300W Power Delivery: Delivers a high-wattage output capability that easily powers heavy inductive or resistive loads.
Heavy Double-Heatsink Layout: Outfitted with two dedicated aluminum cooling blocks mounted directly to the switching chip and Schottky rectifier diode to optimize thermal transfer.
High-Efficiency Energy Switching: Operates with a high-speed internal PWM tracking layout that hits power conversion efficiencies up to 95%, keeping heat generation low.

-25%

Click to enlarge

Back to products

Original price was: ₹400.00.Current price is: ₹300.00.

Characteristic	Specification Parameters
Converter Circuit Core	XL4016E1 Non-Isolated Buck Switching Regulator
Input Supply Voltage (VIN)	7.0V to 40.0V DC (Input must be higher than target output)
Adjustable Output (VOUT)	1.2V to 35.0V DC (Continuously variable via CV trimmer)
Output Current Capacity	0.2A to 8A Continuous (Hits up to 10A Maximum with active fan cooling)
Maximum Output Power	Up to 300W Peak Performance Capacity
Fixed Switching Frequency	180 kHz / 300 kHz (Depending on exact board revision)
Output Voltage Ripple	~50 mV peak-to-peak frequency ripple
Chassis Dimensions	Approx. 65 mm × 47 mm × 24 mm
