Showing all 3 results
Raspberry pi 7-inch Displays Waveshare
Technical Specification Details
| Parameter | Specification Details |
|---|---|
| Display Technology | Transmissive TFT Liquid Crystal Display (LCD) Matrix |
| Native Hardware Resolution | 1024 × 600 Pixels (High-density widescreen ratio) |
| Video Input Protocol | Standard HDMI Interface Type |
| Touch Signal Protocol | Standard Micro-USB I2C Bus Mapping |
| Touch Layout Interface | 5-Point Capacitive Matrix (Operating System dependent) |
| Protective Armor Layer | 6H Structural Hardness Toughened Top Glass |
| Rear Assembly Standoffs | Predrilled to mount Raspberry Pi 4B / 3B+ / 3B directly to the backplate |
| Operating Voltage Target | 5V DC Supply input (drawn over the USB touch port) |
Waveshare 10.1-inch Displays Raspberry Pi
Technical Specification Details
| Parameter | Specification Details |
|---|---|
| Active Screen Proportions | 10.1 Inches Diagonal Length |
| Native Panel Resolution | 1280 × 800 Pixels (High-Contrast Widescreen) |
| Display Technology | QLED (Quantum Dot) Transmissive Active Matrix |
| Color Gamut Spectrum | 100% sRGB | 78% NTSC Wide Gamut Tuning |
| Glass Integration Profile | Full Optical Bonding Encasement Matrix |
| Video Input Protocol | Standard HDMI Input Port Interface |
| Touch Signal Port | Standard Micro-USB Bus Data Link |
| Touch Sensor Engine | 10-Point Capacitive Multi-touch (OS dependent) |
| Touch Glass Rigidity | 6H Structural Hardness Rating |
| Rear Mounting Stand | Pre-drilled spacing to bolt Raspberry Pi 4B / 3B+ / 3B directly to the controller board |
Waveshare 3.5 -inch Displays Raspberry Pi
Technical Specification Details
| Parameter | Specification Details |
|---|---|
| Active Screen Proportions | 3.5 Inches Diagonal Length |
| Native Hardware Resolution | 480 × 320 Pixels (Configurable software scale up supported) |
| Display Panel Architecture | Thin Film Transistor (TFT) Liquid Crystal Display |
| Data Signal Interface | Serial Peripheral Interface (SPI bus) |
| Touch Sensor Engine | Analog Resistive Layer |
| Touch Controller Chip | XPT2046 Integration |
| GPIO Header PIN Allocation | Integrated 26-pin matrix socket (Leaves remaining GPIO free) |
| Target Power Configuration | 5V DC Supply input (drawn over the Raspberry Pi 5V power pins) |
| Structural Dimensions | 85.42 mm × 55.60 mm (Matches standard Pi width/height |
