Name: TB6612FNG Dual DC Motor Driver
SKU: VE-104
Availability: InStock

TB6612FNG Dual DC Motor Driver

Technical Specifications

Characteristic	Specification Parameters
Driver Driver IC	Toshiba TB6612FNG Dual H-Bridge Chip
Motor Supply Voltage (VM)	2.5V to 15.0V DC (Power feed for driven actuators)
Logic Supply Voltage (VCC)	2.7V to 5.5V DC (Compatible with 3.3V and 5V microchips)
Continuous Output Current	1.2A per individual motor channel
Peak Pulse Current Limit	3.2A per individual channel (for short single-pulse durations)
Maximum PWM Frequency	Up to 100 kHz (Supports silent motor operation profiles)
Module Dimensions (approx.)	20 mm × 20 mm × 10 mm (Ultra-compact footprint)

The TB6612FNG Dual DC Motor Driver Module is a highly efficient, ultra-small breakout board designed to govern the speed and bi-directional rotation of two independent brushed DC motors or a single 4-wire stepper motor. Utilizing high-efficiency MOSFET-based H-bridges instead of older bipolar transistors, this module generates minimal internal heat and exhibits a negligible voltage drop across its driver paths. It is the premier compact choice for developing high-performance micromouse maze solvers, lightweight balancing robots, and small autonomous smart cars.

✨ Key Features

High-Efficiency MOSFET Architecture: Delivers significantly lower power waste and lower thermal dissipation than legacy drivers like the L298N, squeezing maximum performance from compact batteries.
Advanced Low-Power Sleep Mode: Features an onboard standby pin (STBY) that puts the control chip into an ultra-low standby state, halting battery drainage during idling cycles.
Dedicated Hardware Braking Support: Provides four functional channel control modes—Clockwise (CW), Counter-Clockwise (CCW), short-brake, and freewheel stop—for precise physical indexing.
Built-in System Safeguards: Outfitted with embedded hardware thermal shutdown protection and an active low-voltage tracking circuit to shield downstream components

-18%

Click to enlarge

Back to products

Original price was: ₹220.00.Current price is: ₹180.00.

Characteristic	Specification Parameters
Driver Driver IC	Toshiba TB6612FNG Dual H-Bridge Chip
Motor Supply Voltage (VM)	2.5V to 15.0V DC (Power feed for driven actuators)
Logic Supply Voltage (VCC)	2.7V to 5.5V DC (Compatible with 3.3V and 5V microchips)
Continuous Output Current	1.2A per individual motor channel
Peak Pulse Current Limit	3.2A per individual channel (for short single-pulse durations)
Maximum PWM Frequency	Up to 100 kHz (Supports silent motor operation profiles)
Module Dimensions (approx.)	20 mm × 20 mm × 10 mm (Ultra-compact footprint)

Compare

Add to wishlist

SKU: VE-104 Category: Motor Driver module
