Name: L293D Dual H-Bridge Motor Driver Module
SKU: VE-101
Availability: InStock

L293D Dual H-Bridge Motor Driver Module

Technical Specifications

Characteristic	Specification Parameters
Driver Board IC	L293D Quadruple Half-H Power Driver Chip
Motor Driving Voltage (VCC2)	4.5V to 36.0V DC (External power input)
Logic Supply Voltage (VCC1)	4.5V to 7.0V DC (Typically 5V from logic controller)
Continuous Current Rating	600 mA maximum per individual channel
Peak Output Current Limit	1.2A per channel for short pulse durations
Thermal Protection Safety	Integrated automatic over-temperature thermal shutdown
Module Dimensions (approx.)	48 mm × 34 mm × 14 mm

The L293D Dual H-Bridge Motor Driver Module (commonly referred to when searching for L293/L293D setups) is a popular, medium-power electronic control card engineered to govern the motion of low-voltage actuators. Built around the standard L293D monolithic integrated push-pull chip, this board isolates low-current microcontroller circuitry from higher inductive currents. It enables developers to manage the speed and bi-directional rotation of two independent brushed DC motors or a single 4-wire bipolar stepper motor, making it a staple for introductory mobile robot bases.

✨ Key Features

Dual Independent H-Bridges: Houses two full physical H-bridge channels, allowing independent forward and backward power cycles for attached loads.
Internal Kickback Protection: Features built-in clamp/clamping diodes that automatically absorb and neutralize back-EMF voltage spikes generated by sudden motor brakes.
Logic and Drive Voltage Separation: Equipped with dedicated independent power inputs, ensuring noisy motor currents do not feed back into stable microcontroller logic rails.
Direct Microcontroller Integration: Built with TTL and CMOS compatible control input pins that wire seamlessly to common systems like Arduino, Raspberry Pi, and ESP32 platforms

-20%

Click to enlarge

Back to products

Original price was: ₹100.00.Current price is: ₹80.00.

Characteristic	Specification Parameters
Driver Board IC	L293D Quadruple Half-H Power Driver Chip
Motor Driving Voltage (VCC2)	4.5V to 36.0V DC (External power input)
Logic Supply Voltage (VCC1)	4.5V to 7.0V DC (Typically 5V from logic controller)
Continuous Current Rating	600 mA maximum per individual channel
Peak Output Current Limit	1.2A per channel for short pulse durations
Thermal Protection Safety	Integrated automatic over-temperature thermal shutdown
Module Dimensions (approx.)	48 mm × 34 mm × 14 mm
