Name: ULN2003 Driver
SKU: VE-098
Availability: InStock

ULN2003 Driver

Technical Specifications

Characteristic	Specification Parameters
Driver Driver IC	ULN2003A (High-Voltage, High-Current Array)
Operating Input Voltage	5.0V to 12.0V DC (Power supply lines isolated from logic inputs)
Max Output Sinking Current	500 mA per channel (Peak current capacity up to 600 mA)
Max Output Standing Voltage	50V DC Peak
Compatible Motor Styles	4-Phase, 5-Wire Unipolar Stepper Motors (e.g., 28BYJ-48)
Logic Control Formats	5V CMOS and TTL Level Logic Inputs
Module Dimensions (approx.)	35 mm × 32 mm × 10 mm

The ULN2003 Stepper Motor Driver Board Module is a compact, high-current electronic switching breakout card designed to control inductive loads from low-power microcontrollers. Populated with a central ULN2003 Darlington transistor array chip, it bridges the current gap between logic boards (like Arduino or ESP32) and actuators. It acts as a set of digital switches, enabling low-current microchip pins to handle heavier current paths safely.

Integrated Darlington Transistor Array: Utilizes high-gain NPN Darlington transistor configurations to cleanly amplify low-power logic inputs.
Built-in Flyback Diodes: Features integrated suppression clamp diodes on each output channel to absorb and dissipate dangerous inductive voltage spikes from motor coils.
Real-Time LED Status Monitoring: Outfitted with 4 independent, on-board LEDs that give immediate visual feedback of active driver phases.
Direct Pluggable Keyed Socket: Includes a standard 5-pin XH-2.54 interface, allowing a 28BYJ-48 stepper motor to plug straight in without loose terminal wires.

-17%

Click to enlarge

Back to products

Original price was: ₹120.00.Current price is: ₹100.00.

Characteristic	Specification Parameters
Driver Driver IC	ULN2003A (High-Voltage, High-Current Array)
Operating Input Voltage	5.0V to 12.0V DC (Power supply lines isolated from logic inputs)
Max Output Sinking Current	500 mA per channel (Peak current capacity up to 600 mA)
Max Output Standing Voltage	50V DC Peak
Compatible Motor Styles	4-Phase, 5-Wire Unipolar Stepper Motors (e.g., 28BYJ-48)
Logic Control Formats	5V CMOS and TTL Level Logic Inputs
Module Dimensions (approx.)	35 mm × 32 mm × 10 mm

Compare

Add to wishlist

SKU: VE-098 Category: Motor Driver module
