Name: RFID Adhesive Tag
SKU: VE-066
Availability: InStock

RFID Adhesive Tag

Technical Specification Details

Parameter	Specification Details
Operating Frequency	13.56 MHz High-Frequency (HF)
Chip Architecture Core	MIFARE Classic 1K Compatible (S50)
Memory Capacity	1024 Bytes (1 KB) EEPROM
Storage Structure Layout	16 Sectors (Each sector contains 4 Blocks; 1 Block holds 16 Bytes)
Unique Identification Number	4-Byte Non-Changeable Unique ID (UID)
Communication Protocol	ISO / IEC 14443 Type A Standard
Adhesive Backing Type	Authentic 3M Heavy-Duty Double-Sided Tissue Tape or equivalent
Sensing Distance Threshold	1 cm to 4 cm (Subject to your reader antenna power profile)
Material Base Finish	Water-Resistant White PVC Coin Disc Profile
Physical Proportions	25.0 mm Diameter × 1.0 mm Thickness

SKU: VE-066 Category: Sensors

Turn any everyday object into a smart access device with this 13.56MHz Round RFID Adhesive Coin Tag. Engineered to offer complete out-of-the-box compatibility with the popular RC522 and PN532 reader/writer modules, this ultra-thin sticker contains an authentic MIFARE Classic 1K chip and an etched micro-antenna. Outfitted with a strong, peel-and-stick adhesive backing, it applies easily to non-metallic surfaces like phone cases, plastic badges, ID cards, books, or product packaging. It is the ultimate choice for custom asset tracking, quick office check-ins, or smart library automation.

Note: This tag is designed for non-metallic surfaces. If applied directly onto metal surfaces (like a bare laptop or metal safe door), the metal will shield the radio frequency. Look for our specialized “Anti-Metal RFID Tags” if sticking onto bare metal.
